Viking 电阻的系列与订货型号怎样核对?

本页的 Viking 指电子元器件品牌 Viking Tech(光颉)。AR 是薄膜精密电阻系列之一;系列、封装、阻值、容差与温度系数需要组合核对,不能把不同规格行中的最优指标拼成一个型号。

光颉(Viking)电阻产品

高精密低温漂电阻

Viking全系代理产品资料

Thin Film Precision Chip Resistor
   高精密薄膜芯片电阻 AR

Viking全系代理产品资料
阻值范围:1Ω~3MΩ
精度:±0.01%~±1%
温漂(ppm/℃):2/3/5/10/15/25/50
封装:0201/0402/0603/
 0805/1206/1210/
 2010/2512

Viking全系代理产品资料

Anti-Corrosive Thin Film Precision Chip Resistor
   抗蚀高精密薄膜芯片电阻PR

Viking全系代理产品资料
阻值范围:10Ω~1.5MΩ
精度:±0.1%~±0.5%
温漂(ppm/℃):15/25/50
封装:0402/0603/0805/
 1206/  2010/2512

Viking全系代理产品资料

Thin Film Anti-Sulfurated Chip Resistor
   高精密薄膜抗硫化芯片电阻TAS

Viking全系代理产品资料
阻值范围:10Ω~499KΩ
精度:±0.05%,±1%
温漂(ppm/℃):10/15/25/50
封装:0402/0603/0805

色环精密电阻

Viking全系代理产品资料

Metal Film Precision Resistor
   金属精密薄膜电阻 CSR

Viking全系代理产品资料
阻值范围:0.1Ω~10MΩ
精度:±0.1%~±5%
温漂(ppm/℃):10/15/25/50/100
封装:0102/0204/0207

Viking全系代理产品资料

Metal Film Precision Resistor
   金属精密薄膜电阻CSRV

Viking全系代理产品资料
阻值范围:0.1Ω~1MΩ
精度:±0.1%~±5%
温漂(ppm/℃):10/15/25/50/100
封装:0204/0207

Viking全系代理产品资料

Carbon Film Resistor
   碳膜无脚电阻CFS

Viking全系代理产品资料
阻值范围:1Ω~1MΩ
精度:±2%,±5%-
封装:0204/0207/0309

Viking全系代理产品资料

Metal Film Leaded Precision Resistor
   插件式金属精密电阻MFR

Viking全系代理产品资料
阻值范围:0.1Ω~10MΩ
精度:±0.05%~±1%
温漂(ppm/℃):5/10/15/25
 50/100
封装:0318/0623/0932
 1145/1550

Viking全系代理产品资料

Metal Film Leaded Resistor
   高精密金属膜固定电阻器MFD

Viking全系代理产品资料
阻值范围:10Ω~1MΩ
精度:±0.02%,±0.05%,
 ±0.1%
温漂(ppm/℃):5/10/15/25
封装:0727/1040

Viking全系代理产品资料

Carbon Film Leaded Resistor
   插件式碳膜电阻CFR

Viking全系代理产品资料
阻值范围:0.1Ω~22MΩ
精度:±2%,±5%-
封装:0318/0623/0932
 1145/1550

Viking全系代理产品资料

Metal Oxide Leaded Film Resistor
   插件式金属氧化皮膜电阻MOF

Viking全系代理产品资料
阻值范围:0.1Ω~22MΩ
精度:±1%,±2%,±5%
温漂(ppm/℃):200
封装:0623/0932/1145
 1550/1765/2485

Viking全系代理产品资料

Metal Film Flame-Proof Resistors
   插件式金属氧化防火电阻FMR

Viking全系代理产品资料
阻值范围:10Ω~1MΩ
精度:±0.1% ~ ±1%
温漂(ppm/℃):15/25/50/100
封装:0623/0932/1145
 1550

电流检测电阻

Viking全系代理产品资料

Current Sensing Chip Resistor
   电流感应芯片电阻CS

Viking全系代理产品资料
阻值范围:1mΩ~8000mΩ
精度:±1%,±2%,±5%
温漂(ppm/℃):100/150/200/300
 400/600/1000
封装:0201/0402/0603
 0805/1206/1210
 2010/2512/1225
 3720/7520

Viking全系代理产品资料

Thin Film Current Sensing Chip Resistor
   薄膜电流感应芯片电阻TCS

Viking全系代理产品资料
阻值范围:50mΩ~1000mΩ
精度:±0.5%,±1%
温漂(ppm/℃):50/100/200
封装:0402/0603/0805
 1206/2010/2512

Viking全系代理产品资料

Current Sensing Thick Film Chip Resistor
   电流感应芯片电阻RS

Viking全系代理产品资料
阻值范围:10mΩ~976mΩ
精度:±1%, ±5%
温漂(ppm/℃):500/800
 1200/1500
封装:0402/0603/0805
 1206/1210/2010
 2512

Viking全系代理产品资料

Ultra Low Ohm (Metal Strip) Chip Resistor 1W~3W
   合金超低阻芯片电阻LR

Viking全系代理产品资料
阻值范围:0.5mΩ~15mΩ
精度:±1%,±3%,±5%
温漂(ppm/℃):50/75/100/150
封装:1206/2010/2512

Viking全系代理产品资料

Chip Shunt Resistor
   分流芯片电阻LRS

Viking全系代理产品资料
阻值范围:0.5mΩ~4mΩ
精度:±1%,±2%,±5%
温漂(ppm/℃):50/60/75
 100/120
封装:1050/1575

Viking全系代理产品资料

Current Sensing Metal Chip Resistor
   电流感应金属芯片电阻CSM

Viking全系代理产品资料
阻值范围:10mΩ~100mΩ
精度:±1%,±2%,±5%
温漂(ppm/℃):50/100
封装:0603/0805/1206
 2010/2512

Viking全系代理产品资料

Low Ohm (Metal Strip) Chip Resistor
   合金低阻芯片电阻LRM

Viking全系代理产品资料
阻值范围:5mΩ~100mΩ
精度:±1%,±2%,±5%
温漂(ppm/℃):75/100
封装:1206/2010/2512

大功率无感电阻

Viking全系代理产品资料

TO-220 Power Resistor
   插件式功率电阻TR20

Viking全系代理产品资料
阻值范围:0.05Ω~1MΩ
精度:±0.5%,1%, 5%,  10%
温漂(ppm/℃):50/100/200/300功率:20W

Viking全系代理产品资料

TO-220 Power Resistor
   插件式功率电阻TR30

Viking全系代理产品资料
阻值范围:0.05Ω~10KΩ
精度:±0.5%,1%, 5%,  10%
温漂(ppm/℃):50/100/200/300功率:30W

Viking全系代理产品资料

TO-220 Power Resistor
   插件式功率电阻TR35

Viking全系代理产品资料
阻值范围:0.05Ω~10KΩ
精度:±0.5%,1%, 5%,  10%
温漂(ppm/℃):50/100/200/300功率:35W

Viking全系代理产品资料

TO-220 Power Resistor
   插件式功率电阻TR50

Viking全系代理产品资料
阻值范围:0.1Ω~10KΩ
精度:±0.5%,1%, 5%,  10%
温漂(ppm/℃):50/100/200/300功率:50W

Viking全系代理产品资料

TO-247 Power Resistor
   插件式功率电阻TR100

Viking全系代理产品资料
阻值范围:0.05Ω~10KΩ
精度:±1%, 5%, 10%
温漂(ppm/℃):50/100/200/300功率:100W

Viking全系代理产品资料

TO-220 Power Resistor
   插件式功率电阻TR50H

Viking全系代理产品资料
阻值范围:0.1Ω~10KΩ
精度:±0.5%,1%, 5%,  10%
温漂(ppm/℃):50/100/200/300功率:50W

汽车级专用电阻 AEC-Q200

Viking全系代理产品资料

Automotive Grade Thin Film Precision Chip Resistor
   汽车等级高精密薄膜芯片电阻AR..A

Viking全系代理产品资料
阻值范围:10Ω~1MΩ
精度:±0.05%~±1%
温漂(ppm/℃):25/50
封装:0402/0603/0805
 1206/1210
 2010/2512

Viking全系代理产品资料

Automotive Grade Chip Resistor
   汽车等级厚膜芯片电阻CR..A

Viking全系代理产品资料
阻值范围:1Ω~10MΩ
精度:±1%, ±5%,
温漂(ppm/℃):100/200
封装:0402/0603/0805/
 1206/1210/2010/
 2512

Viking全系代理产品资料

Automotive Grade Anti-Sulfurated Chip Resistor
   汽车等级抗硫化芯片电阻AS..A

Viking全系代理产品资料
阻值范围:1Ω~10MΩ
精度:±0.5%,±1%,±5%
温漂(ppm/℃):100/200
封装:0402/0603/0805/
 1206/1210/2010/
 2512

Viking全系代理产品资料

Automotive Grade Current Sensing Chip Resistor
   汽车等级电流感应芯片电阻CS..A

Viking全系代理产品资料
阻值范围:1mΩ~8000mΩ
精度:±1%,±2%,±5%
温漂(ppm/℃):100/150/200
 300/400/600
封装:0402/0603/0805
 1206/1210/2010
 2512/1225/3720
 7520

厚膜贴片电阻

Viking全系代理产品资料

Thick Film Chip Resistor
   厚膜芯片电阻CR

Viking全系代理产品资料
阻值范围:1Ω~100MΩ
精度:±0.1%~±5%
温漂(ppm/℃):50/100/200/400
封装:01005/0201/0402
 /0603/0805/1206/
 1210/2010/2512

Viking全系代理产品资料

High Ohmic Chip Resistor
   高阻值厚膜芯片电阻HMR

Viking全系代理产品资料
阻值范围:110MΩ~1GΩ
精度:±5%
温漂(ppm/℃):500/1000
封装:0805/1206

Viking全系代理产品资料

Pulse Withstanding Chip Resistor
   耐突波贴片电阻PWR

Viking全系代理产品资料
阻值范围:1Ω~20MΩ
精度:±0.5%~±5%
温漂(ppm/℃):100/200
封装:0603/0805/1206
 1210/2010/2512

Viking全系代理产品资料

Surge Withstanding Chip Resistor
   抗浪涌芯片电阻SWR

Viking全系代理产品资料
阻值范围:1Ω~20MΩ
精度:±5%~±20%
温漂(ppm/℃):100/200
封装:0603/0805/1206
 1210/2010/2512

Viking全系代理产品资料

High Voltage Thick Film Chip Resistor
   耐高压厚膜芯片电阻HVR

Viking全系代理产品资料
阻值范围:10Ω~100MΩ
精度:±1%,±5%
温漂(ppm/℃):100/200/400
封装:0402/0603/0805
 1206/2010/2512

Viking全系代理产品资料

Anti-Sulfurated Thick Film Chip Resistor
   抗硫化芯片电阻AS

Viking全系代理产品资料
阻值范围:1Ω~10MΩ
精度:±0.5%,±1%,±5%
温漂(ppm/℃):100/200
封装:0201/0402/0603
 0805/1206/1210
 2010/2512

Viking全系代理产品资料

Trimmable Thick Film Chip Resistor
   可雷切芯片电阻RT

Viking全系代理产品资料
阻值范围:1Ω~10MΩ
精度:-10%~-30%
温漂(ppm/℃):100/200
封装:0402/0603/0805
 1206/1210/2010
 2512

排阻

Viking全系代理产品资料

Thin Film Array Chip Resistor
   高精密薄膜芯片排阻TFAN

Viking全系代理产品资料
阻值范围:100Ω~33KΩ
精度:±0.1%,±0.25%
 ±0.5%
温漂(ppm/℃):10/15/25/50
封装:0603x4

Viking全系代理产品资料

Thick Film Array Chip Resistor
   厚膜芯片排阻CN
   CNA

Viking全系代理产品资料
阻值范围:1Ω~1MΩ
精度:±1%,±5%
温漂(ppm/℃):200
封装:0402x4
 0603x4

Viking全系代理产品资料

Thick Film Flat Array Chip Resistor
   厚膜芯片平板排阻CN-21
   CN-41

Viking全系代理产品资料
阻值范围:3Ω~1MΩ
精度:±1%,±5%
温漂(ppm/℃):200/300
封装:0201x2
 0201x4
光颉(Viking)电感产品

贴片高频电感

Viking全系代理产品资料

Thin Film Chip Inductor
   高频薄膜精密芯片电感AL

Viking全系代理产品资料感值范围:0.1nH~33nH
精度:±0.1,0.2,0.3nH
 ±1%,2%,3%,5%
内阻(Ω):0.05~4.5
电流(mA):75~850
封装:0201
 0402

Viking全系代理产品资料

Multilayer Chip Inductor
   高频陶瓷积层电感CL

Viking全系代理产品资料感值范围:0.3nH~470nH
精度:±0.3nH
 ±5%,10%
内阻(Ω):0.05~4.8
电流(mA):50~1000
封装:0201
 0402
 0603

Viking全系代理产品资料

Wire Wound Chip Inductor
   (Low Profile, High Q, Current, High SRF)
   高频陶瓷绕线电感WL

Viking全系代理产品资料感值范围:1nH~15000nH
精度:±2%,3%,5%,10%
 ±2nH, ±5nH
内阻(Ω):0.02~11.5
电流(mA):30~2400
封装:0402
 0603
 0805
 1008
 1206

功率电感

Viking全系代理产品资料

Miniature Wire Wound Power Inductor
   小型绕线功率电感SDIA

Viking全系代理产品资料感值范围:0.9u~470uH
精度:±20%,±30%
内阻(Ω):0.013~7.8
电流(mA):0.24~8.5
封装:0310/0312/0315
 0410/0418/0520
 0528/0610/0612
 0620/0628/0645
 0840

Viking全系代理产品资料

Shielded, Non-shielded, Miniature Wire Wound Power Inductor
   小型绕线功率电感VLH

Viking全系代理产品资料感值范围:0.12u~10000uH
精度:±5%,10%
 ±20%,30%
内阻(Ω):0.0098~140
电流(mA):0.03~6.0
封装:252010E/252012E
 252510
 322515(C)
 322520(C)
 453226(C)
 575047C

Viking全系代理产品资料

Non-shielded, High Power, Wire Wound Power Inductor
   开磁路绕线功率电感PDH

Viking全系代理产品资料感值范围:0.18u~470uH
精度:±20%, ±30%
 +40%-20%
内阻(Ω):0.002~2.3
电流(mA):0.7~30
封装:1608/1813/3316
 4920/5022

Viking全系代理产品资料

Non-shielded, Wire Wound Power Inductor
   开磁路绕线功率电感PD

Viking全系代理产品资料感值范围:0.47u~1000uH
精度:±20%
内阻(Ω):0.008~13.8
电流(mA):0.1~40
封装:1608/3308/3316
 3340/5022

Viking全系代理产品资料

Non-shielded, Low Profile Wire Wound Power Inductor
   开磁路绕线功率电感PCD

Viking全系代理产品资料感值范围:1.0u~1000uH
精度:±10%,20%
内阻(Ω):0.01~26
电流(mA):0.09~9.5
封装:0301/0302
 0403/0502/0503
 0504/0703/0705
 1004/1005/1006

Viking全系代理产品资料

Shielded, Wire Wound Power Inductor
   闭磁路绕线功率电感PS

Viking全系代理产品资料感值范围:1u-10000uH
精度:±20%
内阻(Ω):0.021~32.8
电流(mA):0.02~20
封装:1608/3316/5022

Viking全系代理产品资料

Shielded, Wire Wound Power Inductor
   闭磁路绕线功率电感PCS

Viking全系代理产品资料感值范围:1.0u-1000uH
精度:±20%
 +40%-20%
内阻(Ω):0.007~9.44
电流(mA):0.14~15.9
封装:62B/64B/73/74
 124/125/127

Viking全系代理产品资料

Shielded, Wire Wound Power Inductor
   闭磁路绕线功率电感PCDR

Viking全系代理产品资料感值范围:1.2u~1500uH
精度:±20%,30%
内阻(Ω):0.0069~4.78
电流(mA):0.13~13
封装:0628/0728/0730
 0732/0745/1045
 1255/1265/1275

Viking全系代理产品资料

Shielded, Low Cost, Wire Wound Power Inductor
   闭磁路绕线功率电感PCDS

Viking全系代理产品资料感值范围:4.7u~820uH
精度:±20%,30%
内阻(Ω):0.013~3
电流(mA):0.16~3.15
封装:63B/74B/105B
 125B

Viking全系代理产品资料

Shielded, Low Profile Wire Wound Power Inductor
   闭磁路绕线功率电感PSDB

Viking全系代理产品资料感值范围:0.56u~1000uH
精度:±30%
内阻(Ω):0.006~3.25
电流(mA):0.32~10
封装:5D28
 1003/1004/1005

Viking全系代理产品资料

Shielded, Low Profile Wire Wound Power Inductor
   闭磁路绕线功率电感SCDB

Viking全系代理产品资料感值范围:1.2u~47uH
精度:±20%,30%
内阻(Ω):0.117~2.2
电流(mA):0.22~1.1
封装:2D12/2D15
 2D18

Viking全系代理产品资料

Shielded, Low Profile Wire Wound Power Inductor
   闭磁路绕线功率电感SCDA

Viking全系代理产品资料感值范围:0.47u~100uH
精度:±20%,30%
内阻(Ω):0.035~3.84
电流(mA):0.18~3.9
封装:2D10/2D15/2D18
 3D12/3D15/3D18

Viking全系代理产品资料

Shielded, Low Profile Wire Wound Power Inductor
   闭磁路绕线功率电感SCDS

Viking全系代理产品资料感值范围:1u~680uH
精度:±20%,±30%
内阻(Ω):0.012~6.56
电流(mA):0.13~6.15
封装:3D18/4D18
 4D22/4D28
 5D18/5D28
 6D28/6D38

Viking全系代理产品资料

Shielded Wire Wound Power Inductor
   闭磁路绕线功率电感PCF

Viking全系代理产品资料感值范围:0.36u~2500uH
精度:±20%,30%
内阻(Ω):0.005~57.62
电流(mA):0.036~12.6
封装:4010/4020/4030
 5010/ 5020/5030
 6915/6919/7040
 1015/1040/1062

Viking全系代理产品资料

Shielded, Low Profile Wire Wound Power Inductor
   闭磁路绕线功率电感PDRH

Viking全系代理产品资料感值范围:0.47u~3300uH
精度:±20%,30%
内阻(Ω):0.009~57.62
电流(mA):0.026~4.82
封装:0302/0303/0415
 0502/0503/0603

Viking全系代理产品资料

Shielded, Wire Wound Power Inductor
   闭磁路绕线功率电感SDRH

Viking全系代理产品资料感值范围:1.0u~100uH
精度:±30%
内阻(Ω):0.0095~0.43
电流(mA):0.75~9
封装:0830/0840/0845

Viking全系代理产品资料

Shielded, Wire Wound Power Inductor
   闭磁路绕线功率电感SDB

Viking全系代理产品资料感值范围:0.10u~47uH
精度:±20%
内阻(Ω):0.0005~0.210
电流(mA):3~120
封装:0420/0520/0530
 0620/0625/0630
 0650/1040/1340
 1350/1365

磁芯电感

Viking全系代理产品资料

Multilayer Ferrite Chip Inductor
   积层芯片式黑电感ML

Viking全系代理产品资料感值范围:0.01~33uH
精度:±10%,20%
内阻(Ω):0.07~2.55
电流(mA):5~1800
封装:0603/0805
 0806/1008
 1206

Viking全系代理产品资料

Multilayer Chip Bead
   贴片磁珠CB

Viking全系代理产品资料感值范围:5~2700Ω
精度:±25%
内阻(Ω):0.01~2
电流(mA):50~6000
封装:0402/0603
 0805/1204
 1206/1210
 1808/1812

Viking全系代理产品资料

Wound Chip Inductors (Ferrite)
   铁芯绕线电感(開放,鑄膜及背膠)NL

Viking全系代理产品资料感值范围:47nH~10mH
精度:±5%,10%
 ±20%
内阻(Ω):0.03~150
电流(mA):25~2600
封装:0603/0805
 1008/1210
 1812/2220
插件式电感

Viking全系代理产品资料

DIP Power Inductor

插件式开磁路功率电感DRGH

Viking全系代理产品资料感值范围:10u~47000uH
精度:±10%,20%
内阻(Ω):0.022~96.4
电流(mA):0.038~5.3
封装:654/664/855
 875/895/106
 108/110

Viking全系代理产品资料

DIP Power Inductor

插件式闭磁路功率电感DRGR

Viking全系代理产品资料感值范围:10u~10000uH
精度:±10%,20%
内阻(Ω):0.023~35
电流(mA):0.074~3.51
封装:664/875
 108/110

欢迎光临光頡科技股份有限公司

Viking全系代理产品资料

专业薄膜被动元件制造商



全球被动元件小型化、高频化及高功率,耐压,抗湿已成为主流;现今电子产品快速升级,应用领域更是千变万化,产品多元搭配主流IC才能符合系统产品需求。 光颉科技于1997年10月成立于新竹科学园区,是台湾第一家结合薄膜/厚膜的制程技术与高频被动元件/模组设计开发能力的专业厂商,拥有优越的技术研发团队,致力于薄膜的制程技术研发与高频元件/模组整合的设计开发,提供符合系统产品高频化与小型化需求的整合型被动元件与高频模组等关键零组件。

提供高精密电阻及高频电感

光颉科技利用薄膜制程的高精密特性及厚膜制程的成本优势,开发出特性极佳且独特的精密型电阻, 超低阻值电阻,超低温飘, 拥有最宽广的阻值范围、最精密及最可靠的制程,成为全球少数电阻精度可达0.01%、 TCR 2ppm/℃的制造商。 在高频化的趋势上,我们开发了薄膜式、积层式及绕线式等高频电感元件,亦是全球少数同时拥有此三种制程的制造商,也为了提供更多样不同应用选择,开发了各类功率电感产品, 电感精度可达0.5%,SRF可达13GHz以上, 朝着高频段、 精密、小型化、大电流不断进步。

最可靠信赖的电阻/电感/电容合作伙伴

光颉科技同时也提供客户各种镀膜、黄光制程及客制化(Customer Design)的薄膜/厚膜制程等等代工服务。 为充分满足客户需求, 我们不只提供给给客户特性卓越及极具竞争力的产品外,并积极与客户合作设计开发新产品,在产品效益、特殊电气特性上等等发挥到极致,我们也提供客户所需要的各种电子零组件, 让客户一次购足所需的电阻、电容及电感等等被动元件。

光颉科技广受国内外客户的支持,不断的持续成长,不断开发符合客户需求的新产品,积极扩充产能以符合市场需求。 日益创新的专业技术和遍布全球的行销通路服务客户. 我们的目标是要成为车用产业及高端电子产业关键零组件产品的主要合作供应商。


参数与适用条件

Viking全系代理的参数核对与适用条件
核对项怎样核对需要区分的条件
系列与封装先确认系列,再确认封装和完整型号。相似的外观或字母前缀不能代替订货规则。
容差与温度系数分别核对初始阻值偏差和随温度变化的阻值变化。相同容差不等于相同温度表现。
阻值、功率与电压在所选型号对应的规格行与降额条件下共同核对。不能把最大阻值、最大功率和最低温漂同时套用。

品牌与制造商资料

Viking Tech(光颉)是产品品牌;AR 为其薄膜精密电阻系列。阻容感提供产品资料查询与采购咨询,具体参数以对应型号的制造商文件为准。

具体规格请按完整型号与对应文件版本核对,不同规格行的参数不能合并成通用指标。

选型与采购常见问题

Viking 电阻选型应先确认什么?

先按应用确定薄膜、厚膜或电流检测系列,再核对阻值、精度、温度系数、额定功率与封装。

咨询 Viking 产品需要提供什么?

提供完整型号及后缀、需求数量和应用条件;替代选型还需逐项核对现用器件规格。

相关技术资料

如何辨别Viking与VikingDiodes?识别真假品牌的关键技巧Viking、Vishay与VikingDiodes三者有何区别?深度解析电子元器件品牌差异深度解析:Vishay电容在高性能电路设计中的关键作用VikingDiodes代理Vishay电容:高品质电子元件的可靠之选光颉viking汽车级厚膜贴片排阻(CN..A系列)viking电器中国代理

相关分类
